Haynes Pro

The LAUNCH database packages powered by HaynesPro support technicians in identifying, locating and solving faults on cars and trucks and contain comprehensive repair and maintenance information to reduce the time spent in your professional workshop. The database packages are modular and pre-embedded in our new professional X-431 diagnostic units. The LAUNCH database solutions CarSET PRO and CarSET Ultimate offer not only a broad vehicle coverage, but also optimal support for fault analysis on the vehicle.

CarSET Pro (Car)

The new LAUNCH PRO database package includes many essential features for the workshop. The CarSET PRO database provides instant access to a wide range of Technical Service Bulletins (TSBs), as well as links to fault codes and related case descriptions in original equipment manufacturer (OEM) quality. In addition, it includes tried-and-tested problem solutions and tips as well as guided vehicle diagnostics. The CarSET PRO database also offers wiring diagrams, installation locations and fault code information for all vehicle systems (engine management system, ABS, ESP, air conditioning). The database includes all common data from European and US vehicle manufacturers and is continuously being further developed.

LAUNCH-Europe-CarSET-TruckSET-Datenbank-PRO-Paket-1280x779

Ultimate (Car or Truck)

The LAUNCH Ultimate database package consists of the components Electronics, Tech and Smart. The optimal complete package for your professional workshop! Helps technicians reduce the time spent troubleshooting common faults and includes OEM Technical Service Bulletins (TSBs) and recalls.

Get all the content you need to efficiently deal with various challenges within the automotive aftermarket.

LAUNCH-Europe-CarSET-TruckSET-Datenbank-ULTIMATE-Paket2-1280x765

Electronics

The LAUNCH electronics database supports technicians in identifying, locating and solving faults in electrical systems and components. With the help of intelligent data applications, such as the Vehicle Electronics Smart Assistant, a guided fault analysis is thus possible.

Includes:

Vehicle Electronics Smart Assistant (guided vehicle diagnostics)
Comprehensive and detailed insight into wiring diagrams
Information on fuses and relays

Tech

The LAUNCH Tech database contains extensive vehicle identification, repair and maintenance information, all at your fingertips. Here you will find technical information, repair manuals, technical drawings and much more.

Includes:

Identification data
Maintenance
Setting data
Lubricants and operating fluids
Recalls
Working values

Smart

The LAUNCH Smart database enables technicians to significantly reduce the time needed to troubleshoot common faults. Using OEM Technical Service Bulletins (TSBs) and recall data, the LAUNCH Smart Database provides additional troubleshooting information.

Includes:

Known fixes and tips
Technical Service Bulletins
Recalls

VESA^™ MK II (Guided Diagnosis)

Electrical wiring diagrams for engine management, ABS, ESP and air conditioning system
Component installation locations and information
Error codes (manufacturer and EOBD codes)
Diagnostic assistant
Ground connection points
Link error codes to Smart Module

Fuses and relays

Einbauorte der Sicherungs- und Relaiskästen
Fuses and relays overview

Comfort electrical circuit diagrams

Wiring diagrams including door locks, windows, airbags, exterior lights, start / charge and wash / wiper systems
Move and zoom functions
Highlight function for tracking the corresponding cables and components

Repair manuals

Timing belt; removal/installation
Timing chain; removal/installation
Drive belt; removal/installation
Clutch; removal/installation
Manual gearbox; removal/installation
Cooling system; drain/refill
Engine assembly; removal/installation
Battery procedure
(Semi-)automatic gearbox; check and drain/refill fluid level

Setting data

Power transmission belt
Wheel geometry
Exhaust emission data
Tyre sizes and pressure values
Tightening torques
Service connections air conditioning
Filling quantities

Working values

Overlap technology
Specific and generic values
Follow-up work
Links to generic parts

Lubricants and fluids

Quality and viscosities

Technical drawing

Tightening torques
Links to generic parts

Maintenance

Maintenance plans (of the vehicle manufacturer)
Printable worksheets
Intelligent linking to setting data
Links to generic parts
Follow-up tasks
Additional tasks
Service times
Resetting the maintenance interval display
Timing belt change intervals
Tyre pressure monitoring system

Vehicle identification number

Positions of the vehicle identification numbers and type plates
Vehicle identification number breakdown
Equipment codes

Recalls

Safety-relevant OEM recalls

Recalls

Safety-relevant OEM recalls

Verified problem solutions and tips
(SmartCASE™)

Verified problem solutions and tips
Link to error codes and related cases
